Kvaser Air Bridge Light HS (FCC)

KV-01008-6

by Kvaser AB

$989

Quantity

The Air Bridge Light HS (FCC) from Kvaser is a wireless CAN bridge to connect two CAN networks. It is designed for situations where wired connections are challenging or unsuitable. The Air Bridge Light is comprised of a pair of pre-configured devices with rugged housing and integrated antennas, and allows for the exchange of raw CAN data. The pair attain predictable latency without sacrificing range or stability.

The Kvaser Air Bridge Light comes in two variants: (01008-6) Kvaser Air Bridge Light HS (FCC) is optimized for the US, while (00808-3) Kvaser Air Bridge Light HS is approved for the European Union. Both models share the same functionality but have different radio transmission schemes due to regulatory differences.

Warranty

2-Year Warranty. See Kvaser's General Conditions and Policies for details. Register your product for an additional 1-year Warranty Extension.

Support

Free Technical Support on all products available by contacting support@kvaser.com.

Certifications

The Kvaser Air Bridge Light HS (FCC) (EAN: 73-30130-01008-6) has been tested and found to comply with part 15 of FCC Rules. See User Guide for full FCC Compliance Information Statement..

Features
Technical Specifications
Documentation & Downloads

A pre-configured pair of units that create a point-to-point radio link between two CAN networks
2.4 GHz proprietary protocol
Internal antenna design, antenna output power max 18 dBm
Automatic baud rate detection (125K, 250K, 500K, 1M)
Supports both 11-bit (CAN 2.0A) and 29-bit (CAN 2.0B active) identifiers
High-speed CAN connection (compliant with ISO 11898-2), up to 1 Mbit/s
Power supplied through the CAN bus interface
Rugged aluminum housing
Plug and play, driver-free and configuration-free
Fully compatible with J1939, CANopen, NMEA 2000 and DeviceNet
Extended operating temperature range from -40 to +70 °C

CAN Channels	1
CAN Transceivers	TJA1051T (Compliant with ISO 11898-2)
CAN Controller	Built into the processor
CAN Bit Rate	Autobaud at 1 Mbit/s, 500 Kbit/s, 250 Kbit/s and 125 Kbit/s
Max Message Rate	Approx. 1200 msg/s full duplex
Packet Latency	Approx. 4.8 ms
Wireless Communication	2.4 GHz Gaussian Frequency-Shift Keying (GFSK) with Frequency Hopping Spread Spectrum (FHSS) modulation
Frequency Range	2.405 GHz to 2.477 GHz
Antenna Type	Internal Antenna
Antenna Output Power	Max 18 dBm approx.
Weight	200 g
Dimensions	30 x 151 x 17 mm
Silent Mode	No
External Power	Allowed operating voltage 9 V-36 V DC Maximum input voltage 48 V DC
Power Consumption	Approx. 2 W
Hardware Configuration	Plug and Play
IP Rating	IP 65
Operating temperature	-40 C to +70 C
