- 3x 100BASE-T1 port
- 1x 1000BASE-T port (gigabit Ethernet)
- All Ethernet ports are "switched“ (including the MCU)
- 2x CAN(/FD)
- LIN bus
- USB 2.0
- MicroSD card slot
- 2x Digital output (1x high-side 5V/0.5A, 1x low-side 40V/1A)
- 2x Analogue input (0-30 V)
- Embedded web server for configuration and status information
- User-programmable MCU (C language SDK available free-of-charge)
100BASE-T1 Media Gateway
Regular price
$759 USD
Couldn't load pickup availability
Orders placed before 2:30 Pacific Time usually ship the same day.
Items are delivered with essential accessories and easy-to-follow instructions.
Questions?
Configurable Automotive Ethernet switch and communication bridge
100BASE-T1 Media Gateway is a configurable Automotive Ethernet switch and communication bridge. The device can be used as frame sniffer (Active TAP), employing the packet forwarding function, as well as Ethernet – CAN(/FD) gateway, allowing data to be bi-directionally passed between any of the Ethernet ports and the CAN or CAN FD network.
The gateway features three 100BASE-T1 ports, one Gigabit Ethernet (1000BASE-T or 10/100BASE-TX) port, two CAN(/FD) channels, LIN bus, and a USB port. All Ethernet ports are internally connected to a switch circuit. A microSD card slot, two digital outputs, and two analogue inputs are also available.
The free-of-charge C language SDK allows the user to develop a custom device firmware for monitoring/sniffing, testing and simulations.
Applications:
- Configurable Automotive Ethernet switch
- Active TAP (frame forwarding/sniffing)
- Gateway between Ethernet, CAN(/FD), LIN
- User-programmable gateway / simulator
- Type Gateways & Routers
- Vendor MACH SYSTEMS
- SKU MA-100BASET1-MG
