What is the warranty for Peak-System products?

Here is the complete hardware warranty section from the supplier. PCAN Adapter: PCAN-USB Adapter & PCAN-USB Adapter (Isolated)

I have a PCAN Adapter and have severed my cable to the service port on the engine. I am trying to confirm the wiring to the data link (from the CAN bus side).

These images show the pinout of the CAN bus side: Image 1 Image 2

Do you have a comparable product to Vector’s CANape and canoe/canalyzer?

You may want to look at the PCAN-USB Adapter with PCAN-Explorer 6 from PEAK. It will not be an exact 1:1 replacement, however.

Will the PCAN Adapter (2021, 2022, 4022, etc.) work with my [XYZ] device?

The PEAK PCAN-USB Adapter is a generic CAN interface for PC which allows CAN data exchange according to ISO 11898-2 with CAN bitrates of up to 1 Mbit/s. You will need to check if your devices also use a High-speed CAN connection per ISO 11898-2 standard. If they do, the chances are good that the PCAN-Adapter will work for you. We offer a 30-day money-back guarantee in the event it does not meet your needs.

What chips/circuitry are inside the PCAN USB Adapter?

The PCAN-USB Adapter has an FPGA with all the CAN controller circuitry, power supply circuits, and a CAN transceiver. For additional details, see the features section.

How does it handle 3.3 volt?

The PCAN-USB Adapter (IPEH-002021/22) will work with any CAN device that is ISO 11898-2 compliant. The adapter uses an NXP PCA82C251 CAN transceiver. Here is a link to the transceiver datasheet for full details on CAN voltages: PCA82C251 Datasheet

I ordered 3 PCAN USB adapters. If I want to connect two of them to talk to each other, and they are the only nodes on the CAN bus, what do I need to accomplish this?

You will need a terminated CAN cable such as our PCAN-Cable 2. Or something similar if you already have existing CAN cables. The DB-9 connector on the PCAN-USB Adapter is male. The cable has female connectors and the needed 120 Ohm termination resistors installed at both ends.

What chips/circuitry are inside the PCAN USB Adapter?

The PCAN-USB Adapter has an NXP CAN controller SJA1000 with 16 MHz clock frequency and an NXP CAN transceiver PCA82C251.

I am searching for a professional CAN Bus analyzer. We need the capability to monitor CAN Bus traffic and identify when message faults occur.

The PCAN-USB Adapter with PCAN-Explorer 6 software will serve your needs best!

I purchased the PCAN-USB Adapter (isolated). What else is required to record and then playback J1939 data?

The PCAN-Explorer V6 software with the J1939 add-in will work. We offer a 30-day trial with full functionality. Email us for your trial today.

I see the PCAN USB interface connects to a USB port, and the description says the interface is Linux compatible via SocketCAN. Does the driver present the socketCAN interface 'itself' (the USB interface being transparent), or will I have to provide the transport between the USB interface and the socketCAN interface?

The PEAK-System Linux page answers many of these questions and more. (SocketCAN is relevant for the SYSTEC USB-CANmodul from a different manufacturer.

I think the PCAN-USB Adapter (isolated) will work for the J1939 task I have. What do I need to be able to record and then playback that data?

The PCAN-Explorer V6 software with the J1939 add-in will work. PCAN-Explorer 6 Software

I purchased the PCAN-USB Adapter. Where can I download the driver for this USB adapter?

Windows and Linux drivers can be downloaded from the “Downloads” tab on the product page beneath the product description.

I have a IPEH-002262-KSM01. Do you have any example projects/files for this device? More than the examples provided in the manual?

The manufacturer has packaged all available files and demo projects into this download .

Is your CANopen Source Code UL (Underwriter Laboratories) certified?

No, our products are European, and CE certification is used for hardware, not software.

Can I download the software?

No, the process of getting the software ready and delivered via FTP transfer from SYSTEC usually takes one to two business days.

How do I set a custom CAN baud rate, for example, 333 kHz?

It is not possible to configure a CAN baud rate of exactly 333 kbit/s on the CAN-Ethernet Gateway V2. However, a baud rate of 333,333 kbit/s can be configured and has been tested. Please refer to the user's manual (section 6.4) for instructions on setting the gateway to this CAN baud rate.

Does the CANmodul1 require that a 120-ohm resistor be connected at the input port/CAN side?

Yes, a 120-ohm termination resistor is required at both ends of a CAN bus. If the CANmodul1 happens to be at the end, then an external bus termination is needed.

Will the CAN controller automatically determine whether it's a Standard or Extended ID?

Correct, no special settings are needed. The CAN controller automatically detects if it's 2.0A (11-bit identifier) or 2.0B (29-bit identifier) CAN specification.

What is the return policy?

Most unopened items in new condition and returned within 90 days will receive a refund or exchange. Some items have a modified return policy noted on the receipt or packing slip. Items that are opened or damaged or do not have a receipt may be denied a refund or exchange. Items purchased online or in-store may be returned to any store. Online purchases may be returned via a major parcel carrier. Click here to initiate a return.

How long does it take to process a refund?

We will reimburse you for returned items in the same way you paid for them. For example, any amounts deducted from a gift card will be credited back to a gift card. For returns by mail, once we receive your return, we will process it within 4–5 business days. It may take up to 7 days after we process the return to reflect in your account, depending on your financial institution's processing time.

What is the policy for late/non-delivery of items ordered online?

Our local teams work diligently to make sure that your order arrives on time, within our normaldelivery hours of 9AM to 8PM in the recipient's time zone. During busy holiday periods like Christmas, Valentine's and Mother's Day, we may extend our delivery hours before 9AM and after 8PM to ensure that all gifts are delivered on time. If for any reason your gift does not arrive on time, our dedicated Customer Service agents will do everything they can to help successfully resolve your issue. Click here to complete the form with your order-related question(s).

When will my credit card be charged?

We'll attempt to securely charge your credit card at the point of purchase online. If there's a problem, you'll be notified on the spot and prompted to use another card. Once we receive verification of sufficient funds, your payment will be completed and transferred securely to us. Your account will be charged in 24 to 48 hours.

Will I be charged sales tax for online orders?

Local and State sales tax will be collected if your recipient's mailing address is in: Arizona California Colorado

What software options do I need to purchase for the GEMAC CAN-Bus Tester 2?

There are 5 different add-on software licenses available. You will need one of the add-on licenses if you use a higher layer protocol such as CANopen, J1939, DeviceNet. There are also options for using a Protocol Monitor for one of these protocols. If you just use plain CAN, you may consider the Protocol Monitor CAN-License key for Protocol Monitor CAN (transmit / receive). The available licenses are as follows: CAN-Bus Tester 2: CANopen bus add-on $1039 CAN-Bus Tester 2: DeviceNet bus add-on $1239 CAN-Bus Tester 2: J1939 bus add-on $659 CAN-Bus Tester 2: Protocol Monitor CAN (Rx/Tx) $649 CAN-Bus Tester 2: Protocol Monitor CANopen (Receive) $519 CAN-Bus Tester 2: Protocol Monitor J1939 (Receive) $519

I'm looking at a GEMAC CAN-bus tester 2 for testing of CAN networks in our machines. Will I be able to debug the hardware side with the package by itself? What does the protocol monitor add-on do?

The protocol monitor does the following: CAN: Reception of CAN message frames incl. filtering, Transmission of CAN message frames and sequences (message lists) What level of testing do you plan to do? We're looking at debugging hardware issues with the network, would like to be able to determine problem messages/nodes on the network. I would recommend getting the protocol monitor license along with the CAN bus tester 2 device. Or you can buy the unit by itself first (available from stock) and see if you are okay without that license. You can always buy it at a later point.

What tools are available for developing a Windows-based CANopen application to talk to various CAN devices?

Phytools offers a number of different solutions for CANopen development on a Windows-based system. If you are looking for a full-featured CANopen source code package, we suggest the SYSTEC CANopen Source Code SO-877. This software is a full buyout license, meaning there will be no additional runtime fees or royalties for deployed products with this code inside. It can be used in combination with any SYSTEC CAN interface module. For developing PC-based applications in Windows, we recommend the CANopen Magic Pro DLL developed by our partner Embedded Systems Academy. This software works in combination with any PC-CAN interface made by PEAK-System Technik, such as their popular PCAN-USB Adapters. Embedded Systems Academy also has other CANopen network configuration tools that may be of interest. You can find more information on the Embedded Systems Academy page.

Are there any limitations to the CANopen Magic evaluation copy?

Yes, there are limitations to the CANopen Magic evaluation copy: 1. Communication with a real CAN bus is not possible. Instead, simulated CANopen nodes may be accessed over a purely internal CAN bus. 2. There is no command line interface to access the CAN bus. Please note: The features in this version match the full version of CANopen Magic Ultimate. There are other versions of CANopen Magic available with smaller feature sets. We hope you enjoy using this software and experimenting with CANopen!

Can I try this software before I purchase?

Yes, please email us for a 30-day PCAN Explorer Trial. You must also have a CAN interface, such as the PCAN USB Adapter. Each trial license includes all available add-in options.

I need a software program for collecting data off the J1939 Vehicle Network and parsing out each PGN and identifying which SPNs are available on the network and are changing in values to show it is valid data. What add-in or other product do I need to perform this?

You can do this with PCAN Explorer 6 with the J1939 add-in. We offer a 30-day trial of PCAN Explorer, and the trial comes with all the add-ins. Email us for your trial copy.

What is a .dbc file? (relevant for PCAN Explorer 6 - CANdb add-in)

A DBC file is a Communication Database for CAN. It is the distributed system's backbone. DBC files are basic text files that include information for decoding raw CAN bus data to physical values or in human-readable form. They specify which signals (e.g., RPM, Vehicle Speed, etc.) are contained within specific messages (i.e., CAN IDs). In developing a distributed ECU network based on CAN, a key component is the communication description in the form of DBC files. Described in DBC databases are the properties of the CAN network, the ECUs connected to the bus, and the CAN messages and signals.

My version of PCAN Trace (1.8.0.50) software is giving a bad file error message when trying to read my customers' 2.1 recordings. Can you help?

The PCAN-Trace can only handle trace files which comply with file version 1.x. A trace file that complies with version 2.x must be converted into file version 1.x with the 'PEAK-Converter.'

I am running PCAN Trace and collecting data off the J1939 Vehicle Network. I want to have a program that parses out each PGN and identifies which SPNs are available on the network and are changing in values to show it is valid data. What add-in or other product do I need to perform this?

PCAN Trace cannot do this, but you can do this with PCAN Explorer 6 with the J1939 add-in. We offer a 30-day trial of PCAN Explorer, and the trial comes with all the add-ins.

I am new to EtherCAT. I am looking for an EtherCAT Slave Unit that runs Linux on Raspberry Pi.

Yes, you can accomplish this with the Gateway Module Ethernet Slave coupled with the appropriate base RevPi module (IPC based on Raspberry Pi).

I need to convert two Modbus TCP devices to one Allen Bradley CompactLogix Ethernet IP. Questions I have are:

1. Hardware required. Looks like (1) KU-PR100066 and (1) KU-PR100088 would work? 2. Any additional hardware part number required to do this? 3. Can I convert both signals with one set of converters? A: The two gateway modules you inquired about (KU-PR100066 and KU-PR100088) will work to create a gateway system that connects Modbus TCP with Ethernet IP. The required connection clip is included. No additional items are needed.

Does the RevPi Core or Core 3 come with a power supply cable?

No, there is no cabling included with the RevPi Core or Core 3.

What are the mounting options for the RevPi Core or Core 3?

The RevPi Core or Core 3 can be mounted on a DIN rail housing (for DIN rail version EN 50022).

Does the RevPi Core or Core 3 come with an SD card?

No, there is no SD card included with the RevPi Core or Core 3. You can use a USB memory stick for data storage.

What are the graphics specs of the RevPi Core or Core 3? I need to drive a large LCD display.

The RevPi Core is based on the Broadcom BCM2711, quad-core Arm Cortex-A72. For more information, visit click here The RevPi Core 3 is based on the Broadcom BCM2837 processor. For more information, click here For more information on the VideoCore subsystem, see click here .

What are the limitations of the CANopen Magic evaluation?

The CANopen Magic evaluation has limitations. Please refer to the documentation and licensing information provided by Embedded Systems Academy, Inc.

What is the HS code for the following items: PCAN Cable 1 w/o termination, PCAN T-Adapter, PCAN-USB Adapter

The HTS code for cables and T-adapters is 8544429000. The PCAN-USB adapter is 8517620050. The ECCN number for all products is EAR99. All are manufactured in Germany.

How do I calculate the baud rate?

There is a tool made by PEAK for calculating the baud rate register settings: baudtool.zip

Are the SYS TEC Canmodul1 and the Kvaser Leaf Light v2 the same product essentially?

The two devices provide similar functionality in that they both connect a PC or laptop via its USB interface to a CAN bus. Both devices support the maximum CAN bitrate of 1 Mbit/s. However, both devices have unique designs in terms of internal circuitry and software API/drivers. There are other differences in terms of CAN message throughput, buffer size, etc. If you are using third-party software that specifically requires the use of the Kvaser Leaf Light V2, then I strongly advise against using a different type of USB-CAN interface.

I'm currently using the PCAN-USB to view 500k CAN bus data on cars. I would like to be able to view the LIN bus data on Chrysler vehicles 2011 and newer. Do I need a dedicated LIN interface or is there one that will do both LIN and CAN?

Phytools offers a PLIN-USB Adapter (dedicated LIN interface) and several interfaces that support both CAN and LIN, including the PCAN USB Pro FD, the Kvaser Hybrid, and the CAN FD LIN Gateway.

I am looking for an isolated CAN repeater, and I saw the one you have rated to 500V. Do you have any rated for higher voltages, around 1.5-2 kV?

The PCAN-Repeater DR establishes a galvanic isolation of up to 5 kV according to IEC60601-1 within a High-speed CAN bus. Both CAN ports are decoupled from each other and from the power supply. All message traffic, including error frames, is forwarded 1:1 between both ports. The PCAN-Repeater DR behaves passively and is transparent from the perspective of the CAN bus. LEDs display the current bus status.

I'm currently using the PCAN-USB Adapter to view 500k CAN bus data on cars. I would like to be able to view the LIN bus data on Chrysler vehicles 2011 and newer. Do I need a dedicated LIN interface or is there one that will do both LIN and CAN?

Phytools offers a PLIN-USB Adapter (dedicated LIN interface) and several interfaces that support both CAN and LIN, including the PCAN USB Pro FD, the Kvaser Hybrid, and the CAN FD LIN Gateway.

I am looking for the ability to connect two CAN FD channels and have the ability to process, manipulate, and filter CAN messages bidirectionally between each bus. Which products do I need?

There are two solutions: PC-based solution or a standalone solution. For the former, you can use PCAN-USB Pro FD Adapter, which has two independent CAN FD capable channels. Any message processing, manipulating, filtering, etc. will require using the corresponding PC software based on the PCAN Basic API. For the latter, use the PCAN Router FD with specially programmed firmware as a stand-alone CAN FD router.

I just need a simple CAN interface with some software that can receive and display CAN messages from other nodes as well as send CAN messages out to other nodes. What device would you recommend?

We suggest a PCAN-USB Interface with the included free PCAN-View software. If you need a device that is able to detect and analyze more of the physical layer properties of a CAN system, we do offer CAN diagnostic tools as well.

Products

Sort by

Show
24
36
48

View as

Sale

$59

Kvaser DB9-Power Inlet
Kvaser AB

The Kvaser DB9-Power Inlet is a power injector for CAN busses from a DC power jack into one female D-SUB9 connector and also has one unpowered male...
View full details

$59

Sale
Sale

$1,799

Kvaser DIN-Rail SE400S-X10
Kvaser AB

4 x CAN FD Interface The Kvaser DIN Rail SE400S-X10 is a multi-channel, programmable Ethernet to CAN/CAN FD interface for DIN Rail mounting. The de...
View full details

$1,799

Sale
Sale

$295

Kvaser DIN-Rail SE400S-X10 Analog add-on
Kvaser AB

Kvaser DIN Rail S020-X10 Analog is an optional add-on module to the Kvaser DIN Rail SE400S-X10 base module. With four analog inputs and four output...
View full details

$295

Sale
Sale

$295

Kvaser DIN-Rail SE400S-X10 Digital add-on
Kvaser AB

Kvaser DIN Rail S010-X10 Digital is an optional add-on module to the Kvaser DIN Rail SE400S-X10 base module* with 16 digital inputs and 16 digital ...
View full details

$295

Sale
Sale

$295

Kvaser DIN-Rail SE400S-X10 Relay add-on
Kvaser AB

Kvaser DIN Rail S030-X11 Relay is an optional add-on module to the Kvaser DIN Rail SE400S-X10 base module with eight N.O. (Normally Open) relays an...
View full details

$295

Sale
Sale

$822

Kvaser Ethercan HS
Kvaser AB

CAN to Ethernet interface for remote network access. Supports REST API and t-programming. The Kvaser Ethercan HS is a powerful, real-time Ethernet ...
View full details

$822

Sale
Sale

$661

Kvaser Ethercan Light HS
Kvaser AB

CAN to Ethernet interface for remote network access. The Kvaser Ethercan Light HS is a CAN to Ethernet interface that, when linked over the Interne...
View full details

$661

Sale
Sale

$759

Kvaser Hybrid 2xCAN/LIN
Kvaser AB

Kvaser Hybrid 2xCAN/LIN is a flexible, dual channel interface that allows each channel to be assigned independently as CAN or LIN. This makes the K...
View full details

$759

Sale
Sale

$1,159

Kvaser Hybrid Pro 2xCAN/LIN
Kvaser AB

Kvaser Hybrid Pro 2xCAN/LIN is a flexible, dual channel interface that allows each channel to be assigned independently as classic CAN, CAN FD or L...
View full details

$1,159

Sale
Sale

$440

Kvaser Leaf Light HS GI
Kvaser AB

NOTE: This product version has been discontinued by the manufacturer and is no longer available to purchase. The recommended replacement product is...
View full details

$440

Sale
Sale

$325

Kvaser Leaf Light HS OBDII
Kvaser AB

NOTE: This product version has been discontinued by the manufacturer. Contact Phytoolsfor stock availability. Replacement product is Kvaser Leaf Li...
View full details

$325

Sale
Sale

$334

Kvaser Leaf Light HS v2
Kvaser AB

The sleek and ergonomically designed Kvaser Leaf Light V2 represents one of the most cost-efficient and easy ways of connecting a laptop or desktop...
View full details

$334

Sale
Sale

$345

Kvaser Leaf Light HS v2 J1939-13 Type II
Kvaser AB

Kvaser's Leaf Light HS V2 J1939-13 Type II is the latest version of Kvaser's popular line of Leaf Light V2 USB-to-CAN interfaces. This application ...
View full details

$345

Sale
Sale

$359

Kvaser Leaf Light HS v2 M12
Kvaser AB

Kvaser's Leaf Light HS V2 M12 is the marine version of Kvaser's popular line of Leaf USB-to-CAN interfaces. This device offers a simple way of conn...
View full details

$359

Sale
Sale

$334

Kvaser Leaf Light HS v2 OBD2
Kvaser AB

Kvaser's Leaf Light V2 OBD2 is the latest version of Kvaser's popular line of Leaf Light V2 USB-to-CAN interfaces. This application specific device...
View full details

$334

Sale
Sale

$515

Kvaser Leaf Light R v2
Kvaser AB

Kvaser Leaf Light R v2 (with Galvanic Isolation) is a one channel USB interface for CAN. In hostile environments where dust and water are the norm,...
View full details

$515

Sale
Sale

$528

Kvaser Leaf Light Rugged HS
Kvaser AB

NOTE: This product has been designated Not For New Design (NFND), effective September 27, 2017. We encourage customers to migrate to the newest ver...
View full details

$528

Sale
Sale

$315

Kvaser Leaf Light V2 HS J1939-13
Kvaser AB

This product is no longer available. Please consider the newer model, the Kvaser Leaf Light HS V2 - J1939 Type II.This product is EOL. Please see t...
View full details

$315

Sale
Sold out

$859

Kvaser Leaf Pro HS V2
Kvaser AB

Kvaser's latest addition to the popular "Leaf" family brings programmability to user’s fingertips along with support of the faster CAN with Flexibl...
View full details

$859

Sold out
Sale

$859

Kvaser Leaf Pro HS V2 OBD2
Kvaser AB

Please consider either the Kvaser U100P-X3 or the Kvaser U100-X3 the replacement Kvaser's latest addition to the popular "Leaf" family brings prog...
View full details

$859

Sale
Sale

$785

Kvaser Leaf Professional HS
Kvaser AB

This product is no longer available. The replacement model is the Kvaser Leaf Pro HS V2Kvaser Leaf Professional is a single-channel, high performan...
View full details

$785

Sale
Sale

$785

Kvaser Leaf Professional HS OBDII
Kvaser AB

This product is no longer available. The replacement model is the Kvaser Leaf Pro HS V2 OBDII.Kvaser Leaf Professional is a one channel, high perfo...
View full details

$785

Sale
Sold out

$599

Kvaser Leaf Professional LIN
Kvaser AB

This product is EOL as of Jan 2023. Please consider the Kvaser Hybrid Pro CAN/LIN as the recommended replacement. The Kvaser Leaf Professional LIN...
View full details

$599

Sold out
Sale

$785

Kvaser Leaf Professional LS
Kvaser AB

This product is EOL as of Jan 2023. Please consider the Kvaser U100 or the Kvaser U100P as the recommended replacements. Kvaser Leaf Professional i...
View full details

$785

Sale
Sale

$833

Kvaser Leaf Professional Rugged HS
Kvaser AB

This product is EOL as of Jan 2023. Please consider the Kvaser U100 or the Kvaser U100P as the recommended replacements. Kvaser Leaf Professional R...
View full details

$833

Sale
Sale

$785

Kvaser Leaf Professional SWC
Kvaser AB

This product is EOL as of Jan 2023. Please consider the Kvaser U100 or the Kvaser U100P as the recommended replacements Kvaser Leaf Professional is...
View full details

$785

Sale
Sale

$349

Kvaser Leaf v3
Kvaser AB

The Kvaser Leaf v3 represents one of the easiest and lowest-cost methods of connecting a computer to a CAN bus network in order to monitor and tran...
View full details

$349

Sale
Sale

$359

Kvaser Leaf v3 CB
Kvaser AB

'Bare board' version of the popular Kvaser Leaf v3 The Kvaser Leaf v3 CB is the circuit board version of Kvaser's popular single-channel, high spe...
View full details

$359

Sale
Sale

$1,365

Kvaser Memorator 2xHS v2
Kvaser AB

The Memorator 2xHS v2 is a compact, dual channel CAN bus interface and standalone data logger that allows users to monitor and collect data from tw...
View full details

$1,365

Sale
Sale

$1,240

Kvaser Memorator HS/HS CAN Datalogger
Kvaser AB

This product has been discontinued, and has been replaced by the Kvaser Memorator 2xHS v2 (KV-00821-2). Kvaser Memorator is a dual channel CAN bus ...
View full details

$1,240

Sale
Sale

$1,240

Kvaser Memorator HS/LS CAN Datalogger
Kvaser AB

Kvaser Memorator is a dual channel CAN bus interface as well as standalone CANbus data logger. When operated in stand-alone mode this device logs d...
View full details

$1,240

Sale
Sale

$1,240

Kvaser Memorator HS/SWC CAN Datalogger
Kvaser AB

Kvaser Memorator is a dual channel CAN bus interface as well as standalone CANbus data logger. When operated in stand-alone mode this device logs d...
View full details

$1,240

Sale
Sale

$1,422

Kvaser Memorator Pro 2xHS V2
Kvaser AB

Professional dual-channel standalone data logger and USB to CAN interface with t-Program. Kvaser Memorator Pro 2xHS v2 is a professional-level, pro...
View full details

$1,422

Sale
Sale

$1,480

Kvaser Memorator Pro 2xHS v2 CB
Kvaser AB

The Kvaser Memorator Pro 2xHS v2 CB is the bare circuit board version of the professional-grade, dual-channel CAN (Controller Area Network) bus int...
View full details

$1,480

Sale
Sale

$2,829

Kvaser Memorator Pro 5xHS
Kvaser AB

Professional five channel standalone data logger and USB-to-CAN/CAN FD interface with t-Program. The Memorator Pro 5xHS made by Kvaser is a five ch...
View full details

$2,829

Sale
Sale

$2,750

Kvaser Memorator Pro 5xHS CB
Kvaser AB

The Memorator Pro 5xHS CB is a bare circuit board version of a five channel, high performance CAN (Controller Area Network) bus interface and stand...
View full details

$2,750

Sale
