Kvaser PCIe 8xCAN

SKU #: KV-01512-8
New

Your Gateway to Efficient Connectivity

Maximize your advanced CAN system effortlessly with the Kvaser PCIe 8xCAN, a compact, scalable, and real-time interface offering eight CAN/CAN FD channels in a single PCIe x1 slot, ideal for high-density applications like automotive HIL testing.

The Kvaser PCIe 8xCAN maximizes channel density through a single PCIe x1 slot, enabling the effortless design of advanced CAN systems.

It is a compact and advanced multi-channel real-time CAN interface with eight CAN/CAN FD channels.

The Kvaser PCIe 8xCAN is highly scalable. Multiple boards can be connected to capture data from tens of CAN channels at a time. An example is hardware-in-the-loop (HIL) suites for automotive testing, where 40 CAN channels are commonly required.

(Also available in a quad-channel or a single-channel version.)


Major features:

  • PCI Express CAN interface.
  • Supports CAN FD, up to 8 Mbit/s.
  • Quick and easy plug-and-play installation.
  • Supports both 11-bit (CAN 2.0A) and 29-bit (CAN 2.0B active) identifiers.
  • 100 % compatible with applications written for other Kvaser CAN hardware with Kvaser CANlib.
  • High-speed CAN connection (compliant with ISO 11898-2), up to 1 Mbit/s.
  • Supports silent mode for analysis tools – listens to the bus without interfering.
  • Supports simultaneous usage of multiple Kvaser interfaces.
  • Full-profile PCIe card.
  • Support for SocketCan.
  • Compatible with J1939, CANopen, NMEA 2000® and DeviceNet. Higher layer protocol translation handled by the user’s application.

Property Value
The information herein is subject to change without notice.
Galvanic Isolation Yes
Bitrate 20-1000 kbit/s
Silent mode Yes
Error frame generation Yes
CAN FD bitrate
up to 8 Mbit/s
Weight 72 grams
Timestamp resolution 1 μs
CAN channels 8
Temperature range -40°C to +85°C
Dimensions  High profile, 102 x 80 mm
Kvaser DIADEM Driver
Kvaser Drivers for Windows
Kvaser CANKing
A free of charge general-purpose CAN bus momnitor. Works with all CAN interfaces from Kvaser as well as the virtual CAN bus.
Version V6.25.575
Kvaser CANlib SDK
Kvaser LabView VI Library for CAN
Kvaser Linux Driver and SDK
