- One device for desktop and laptop
- Functionality of a standalone CAN bus data logger and a USB CAN bus interface in a single device
- Support for Kvaser Linx J1587
- Quick and easy plug-and-play installation
- Supports both 11-bit (CAN 2.0A) and 29-bit (CAN 2.0B) identifiers
- CAN messages are time-stamped with 2 microseconds resolution
- Large on-board RAM buffer for CAN messages
- 100% compatible with applications written for Kvaser Leaf, LAPcan, PCIcan, PCcan, USBcan, etc., with Kvaser's CANlib
- Galvanic isolation to protect the hardware
- Power from CAN bus or from the USB side
- Built-in real time (calendar) clock with battery backup
- Logger status is indicated with five externally visible LEDs
- IP67 rated lightweight aluminium housing
| Property | Value |
|---|---|
| The information herein is subject to change without notice. | |
| Galvanic Isolation | Yes |
| Bitrate | 20-1000 kbit/s |
| Silent mode | Yes |
| Error frame generation | Yes |
| Error frame detection | Yes |
| Weight | 190 grams |
| Timestamp resolution | 2 |
| On board buffer | Yes |
| Maximum message rate, send | 20000 |
| Maximum message rate, receive | 20000 |
| Sound | No |
| Clock synchronization | MagiSync |
| Dimensions (WxLxH) | 30x200x20 mm (1.2x7.9x0.8in.) |
| Datasheet |
| Kvaser Memorator R SemiPro Datasheet |
| Kvaser Memorator R SemiPro Users Guide |
| User guide for Memorator R SemiPro Version V6.3.220215 |
| Kvaser Database Editor Users Guide |
| Kvaser Database Editor User's Guide Version 2.0.0 |
| Kvaser Memorator Professional Trigger Guide |
| Introduction to Kvaser Memorator Tools for Kvaser Memorator Professional. Version 2.0.0 |
| Kvaser Memorator Tools Introduction |
| Introduction to Kvaser Memorator Tools for Kvaser Memorator Professional. Version 1.0.0 |
| Kvaser SocketCAN Device Drivers |
| Kvaser SocketCAN Drivers for Linux. Version V1.10.477 |
| Kvaser Linux Driver and SDK |
| Linux driver and SDK for Kvaser PCIcan/PCIcanx, Kvaser PCIcanII, Kvaser PC104+, Kvaser PCIcanx II, Kvaser USBcan II, Kvaser Memorator*, Kvaser Leaf family, Kvaser Memorator Pro**, Kvaser USBcan Pro and VirtualCAN. For LAPcan and LAPcan II, you should use version 4.2 of the driver. (*) only with USBcanII functionality, (**) only with USBcan Pro functionality Version V5.38.841 |
| Kvaser DIADEM Driver |
| This free driver for National Instrument's DIAdem supports all CAN hardware from Kvaser. Version V4.1.0 |
| Kvaser Drivers for Windows |
| Windows drivers for all our CAN hardware. Please check release notes for information on which Windows versions are supported. It also contain a driver for the virtual CAN bus. Version V5.38.841 |
| Kvaser Firmware Update Tool |
| Firmware Update tool for most Kvaser devices. Version V4.27.841 |
| Linux SDK Library |
| Linux SDK library. Version V5.38.841 |
| Python module |
| The Canlib module is a Python wrapper for Kvaser CANlib SDK. Version V1.20.360 |
| Kvaser LabView VI Library for CAN |
| Library for National Instrument's LabView. Version for all Kvaser CAN hardware. Version V19.3.0 |
| Kvaser CANlib SDK |
| Software development kit - everything you need to develop software for the Kvaser CAN and LIN interfaces. Libraries, header files, sample programs for e.g. C, C++, C#, Visual Basic and Delphi, documentation, and more. Note: you need to download and install the appropriate device drivers separately. Version V5.38.841 |
| Kvaser Database Editor |
| Standalone installer for Kvaser Database Editor. Version V2.5.475 |
| Kvaser Memorator Tools |
| Logger setup and configuration program for Kvaser Memorator Professional, Kvaser Memorator and Kvaser Memorator Light. Version V4.26.841 |
| Kvaser CANKing |
| A free of charge, general-purpose CAN bus monitor. It works with all CAN interfaces from Kvaser and also with the virtual CAN bus. Version V6.21.288 |
